8-Spindle CNC Curtain Wall Drilling Machine
The Lebulang brand 8-Spindle CNC Curtain Wall Drilling Machine is a high efficiency, multi spindle CNC drilling machine specially designed for aluminum curtain wall profiles, window & door aluminum profiles, and long industrial aluminum profiles. It is widely used in high volume production of curtain wall fabrication, enabling 8 holes drilled simultaneously with one clamping, greatly improving productivity and ensuring consistent accuracy,shandong Lebulang Precision Machinery Co., Ltd welcome you to visit.
Manufactured by Lebulang Machine, a China-based window and door machinery manufacturer with over 30 years of factory experience. This 8-Spindle CNC Curtain Wall Drilling Machine is built for aluminum curtain wall profiles, window and door profiles, and industrial aluminum sections. Each of the 8 spindles is driven by a 0.75 kW motor, with a maximum drilling diameter of 13 mm and a feed stroke of 125 mm. The machine runs on 380V three-phase power and requires a working air pressure of 0.5–0.8 MPa.
The maximum profile section is 250×250 mm, and the processing length reaches 5000 mm. Minimum hole spacing is 350 mm, with individual working tables sized 300×300 mm. Overall dimensions are 5500×1100×1800 mm. Typical applications include unitized and stick curtain wall fabrication, mounting and connection holes in industrial aluminum profiles, and general architectural aluminum processing.
The equipment is CE and ISO certified. OEM and customized configurations are supported. Factory-direct supply with design emphasis on easy maintainability and remote installation guidance provided at no additional cost.
Technical Specifications
| Item | Parameter |
| Model | 8‑Head CNC Aluminum Curtain Wall Drilling Machine |
| Number of heads | 8 pcs（0.75 kW each） |
| Power supply | 380V / 50Hz / 3‑phase |
| Max drilling diameter | 13 mm |
| Drilling feed stroke | 125 mm |
| Working air pressure | 0.5--0.8 MPa |
| Max profile section | 250×250 mm |
| Max processing length | 5000 mm |
| Min distance between holes | 350 mm |
| Working table size | 300×300 mm |
| Overall dimension（L×W×H） | 5500×1100×1800 mm |
| Factory place | Jinan City |
8‑Head CNC Aluminum Curtain Wall Drilling Machine Applications
- Aluminum curtain wall profiles（unitized & stick curtain wall）
- Aluminum window & door profiles
- Industrial aluminum profiles（mounting holes, connection holes）
- Facade & architectural aluminum fabrication
FAQ
1. Are you manufacturer?
Yes, we are the professional manufacturer with more than 30 years experience in this area.
2. What's the delivery time for the machines?
Normal machines our delivery time is 20 days after getting deposit, customized machines should confirm with our sales persons.
3. How about the after-sale service?
- 1). reply it at once when machines break down, it reply it within 12 hour
- 2). if clients need, we can appoint engineers to help install the machines and train the workers
4. What's the guarantee time?
- 1). All machines guarantee time is one year, not including wearing parts.
- 2). If machines parts broken, we will give for free, but clients should afford courier fees.
- 3). 24 hours on line service each day, free technical support.
5. Do you provide equipment operation training?
Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. Also support online training.
6. What is the payment terms?
Any payment method you want, such as T/T, L/C and so on.
